SAVOX C-C550/DT Remote Speaker Mic

Product code: L553003-11F1100

SAVOX C-C550/DT product variant is specifically designed to be compatible with Entel radios.

The SAVOX C-C550 is a combined remote speaker microphone and body worn push-to-talk unit. It is rugged and has been extensively tested (MIL-STD-810G) to provide robust and reliable communications for professionals working in harsh conditions. The C-C550 is dust tight and submersible in water up to 1m (IP67). The SAVOX C-C550 enables effective remote communications with the radio positioned under clothing and when wearing heavy gloves. Remote activation of the radio’s emergency button (radio specific) provides an additional safety feature. EX version of the C-C550 comes with dark blue PTT buttons.

Key Benefits

Dust proof and water submersible (IP67)
Extremely rugged design and large PTT buttons
Excellent tactile feel and operation even with thick gloves
Exceptional speaker audio performance in noisy and harsh environments
MIL-STD-810 tested
Ex version

Additional Information

Market Segment	Public Safety
Product code	L553003-11F1100
Size L	79 mm
Size W	37 mm
Size H	115 mm
Housing Material	Conductive Plastic
Housing Colour	Black
Weight	170 g
Operational Temperature Min	-40 °C (-40 °F)
Operational Temperature Max	85 °C (185 °F)
Ingress Protection	IP66, IP67
Storage Temperature Min	-25 °C (-13 °F)
Storage Temperature Max	70 °C (158 °F)
Protection Against Drop(fall)	1 meter
RX audio SPL( XXdB; X,X W; X,X m)	90dB/0.5W/0.2m
TX Audio, Microphone Sensitivity(XXdB +-XdB)	-39dB +/-2dB
Microphone Type	Omnidirectional
Headset Connector	QR4+1 female
Use Voltage	3.0...10.0VDC(0VDC for dynamic microphone)
Ex/IS	ATEX / IECEx
Emergency Button	Yes
Attachment/Fastening	Clothing Clip
Price List Notes	Ex II 2 GD Ex ib IIC T4 Gb Ex ib IIIC T99'C Db Ta: -20'C... +55'C
